Processing Equipment
Shinwa Moulds has created and developed an advanced in-house tool shop with new acquisitions like High speed Milling Centers, Double head EDM & Gundrilling machinery. This ensures the benefit of the latest technology and the greatest capacity to satisfy the demanding needs of our clients. Here we can build moulds with a higher degree of secrecy and strict confidentiality. Our tool shop, supported by more than 100 highly skilled employees, offers unlimited opportunities to develop and execute complex custom configurations.
Assembly Shop
Our tool shop stands as the primary pillar for precision mould assemblies. Through strategic equipment acquisitions and technical expansions, we have established robust assembly workflows. With a climate-controlled assembly environment, high-precision gauges, and rigorous inspection, we harness the benefits of modern technology to provide unmatched capacity, ensuring that every tool meets structural, flow, and tolerance benchmarks.
Shop Floor Gallery
High fidelity visual overview of our active facility in Bawal.
SHINWA UNIT 01 CNC SECTION
Fully automated CNC Vertical Machining Centers configuration.
| S.No. | Machine Name | Machine Make | RPM | Bed Size | Travel Size | Loading Cap. | Qty. |
|---|---|---|---|---|---|---|---|
| 1 | TAKUMI V18 | Takumi | 12000 | 2000x850 MM | 1800x750x550 MM | 2.5 TON | 1 |
| 2 | TAKUMI H-10 | Takumi | 16000 | 1070x750 MM | 980x700x450 MM | 0.8 TON | 1 |
| 3 | TAKUMI HIGH SPEED | Takumi | 30000 | 600x550 MM | 600x500x350 MM | 2.5 TON | 1 |
| 4 | TAKUMI VC-0852 | Takumi | 10000 | 850x550 MM | 850x520x450 MM | 2.5 TON | 1 |
| 5 | MA-850 TAKUMI | Takumi | 10000 | 850x550 MM | 700x520x500 MM | 2.5 TON | 1 |
| 6 | BMV-65 | - | 8000 | 1500x700 MM | 1280x650x650 MM | 2.5 TON | 1 |
| 7 | BFW-45 | - | 8000 | 900x450 MM | 600x450x500 MM | 2.5 TON | 1 |
| 8 | GUNDRIL KGD KOREA | KGD Korea | VARIABLE | 2500x1500 MM | 2000x1200 MM | 15 TON | 1 |
SHINWA UNIT 01 EDM SECTION
High performance electrical discharge machine centers.
| S.No. | Machine Name | Machine Make | Remarks | Bed Size | Travel Size | Loading Cap. | Qty. |
|---|---|---|---|---|---|---|---|
| 1 | EDM DOUBLE HEAD MIRROR DICK | Mirrordick | 2 HEAD | 1300x600 MM | 700x500x400 MM | 4.5 TON | 2 |
| 2 | SPARKONIX CNC EDM | Sparkonix | - | 1000x600 MM | 1000x600x550 MM | 3.5 TON | 1 |
| 3 | SPARKONIX ZNC EDM | Sparkonix | - | 400x600 MM | 500x300x250 MM | 2.0 TON | 2 |
| 4 | CNC EDM MIRRORDICK | Mirrordick | - | 700x400 MM | 400x300x300 MM | 0.7 TON | 1 |
SHINWA UNIT 02 CNC SECTION
Heavy-duty double column and vertical machining centers.
| S.No. | Machine Name | Machine Make | RPM | Bed Size | Travel Size | Loading Cap. | Qty. |
|---|---|---|---|---|---|---|---|
| 1 | AWEA CNC DOUBLE COULMN | AWEA | 10000 | 3260x1600 MM | 3000x1200x760 MM | 2.5 TON | 1 |
| 2 | AWEA VERTICAL MACHINING CENTER | AWEA | 10000 | 1050x660 MM | 850x660x500 MM | 0.85 TON | 1 |
| 3 | TAKUMI VERTICAL MACHINING | Takumi | 10000 | 1050x600 MM | 1000x500x500 MM | 0.85 TON | 1 |
OTHER SUPPORTING MACHINES
Additional precision equipment for comprehensive toolroom capabilities.
| S.No. | Machine Name | Bed Size / Specs | Loading Cap. |
|---|---|---|---|
| 1 | INJECTION MOULDING MACHINE 450T | 760x710x1500 MM (MAX:780 MIN:330) | 1.5KG SHOT |
| 2 | INJECTION MOULDING MACHINE 1300T | 1530x1120x3000 MM (MAX:1500 MIN:750) | 1.5KG SHOT |
| 3 | DIE SPOTTING MACHINE | 2100x1800x2100 MM | 200 TONNAGE |
| 4 | LASER WELDING MACHINE | 400 kw | 1.5 TON |
| 5 | CMM (ACCURATE) | 1000x800x600 MM | 0.8 TON |
Molding Machine - Trial Purpose
Injection molding machines dedicated for in-house mould trial purposes.
INJECTION MOULDING MACHINE 450T
Dedicated injection molding machine for in-house mould trial purposes.
Key Specifications
INJECTION MOULDING MACHINE 1300T
Dedicated injection molding machine for in-house mould trial purposes.
Key Specifications
Specialized Tryout & Press Machines
Equipped with heavy-tonnage presses for in-house mould spotting and validation.
DIE SPOTTING MACHINE
Advanced die spotting press ensuring perfect alignment, matching, and safe handling of large and complex moulds.
